PolyMide PA6-GF Grey - 1.75mm - 2 kg
Ref. PG02003
PolyMide PA6-GF Polymaker Grey is a fibreglass-reinforced PA-6 nylon that is highly resistant to impact and heat (191°C). Available in 1.75mm and 2kg versions.
€131.95 excl. VAT
VAT at 0%, which is €131.95 TTC including tax.
Ordered before 1:00 PM, delivered to your doorstep tomorrow!
Delivery within 48/72 hours
Order before 1pm. Same day shipping
Free delivery
Free delivery near you from €69.90
Premium support
Our teams are on hand to answer all your questions
Over 2000 products
A wide choice of products from the biggest brands
Use of PolyMide PA6-GF Grey 1.75mm - 2kg
PolyMide PA6-GF Grey 1.75mm developed by Polymaker is a very strong , impact-resistant 3D material.
Also developed to withstand high temperatures(191°C), it can be used to make gear-type parts with excellent strength and durability.
This PA6-6 fibreglass-reinforced material is widely used for 3D printing parts in environments where temperatures can reach 190°C.
With its excellent inter-layer adhesion, this premium PA6-GF is easier than PA6 to print and retains high dimensional accuracy.
Thanks to the Warp-Free technology developed by Polymaker, this 3D thread can also be printed without a print chamber.
PolyMide PA6-GF Grey 1.75mm: highlights
Resistant to high temperatures: PolyMide PA6-GF Grey from Polymaker offers high thermal resistance (191° C).
Layer adhesion: PolyMide PA6-GF Grey provides excellent layer adhesion thanks to the controlled dispersion of its Polyamide matrix.
High strength: PolyMide PA6-GF is a filament with very high rigidity and durability (Charpy: 16.5 kJ/m2).
Our recommendations for use with PolyMide
3D printing of PolyMide PA6-GF Grey requires an extrusion temperature of between 280 and 300°C, a platen heated to between 25 and 50°C (maximum) and a print speed of 60 to 70mm/s.
3D printing of glass-fibre reinforced nylon is abrasive, so the use of an abrasion-resistant nozzle such as Solex3D with a Ruby nozzle is highly recommended. After only 100g printed, a standard nozzle can be completely damaged.
To obtain the maximum properties from your 3D part, baking the part for 2 hours in an oven is ideal.
The use of a double extrusion 3D printer for 3D printing parts with complex geometries is useful. In this case, it is preferable to use a dedicated support material of the type Polydissolve specifically designed by the same manufacturer.
Finally, we recommend storage in a dedicated box such as a PolyBox to prevent the material from absorbing moisture. If this is the case, drying at 80°C for 12 hours in a conventional oven is necessary.
This PA6-GF Grey filament is compatible with most 3D printers on the market and is available in versions 1.75mm and 2.85mm as well as 2kg and 2kg.
- 🎯 We collaborate with businesses.
- 📦 Stock in Europe
- 🚚 Ships within 24 hours
- 🔐 Secure payments
- 🔙 14 days to change your mind
- 📱 Need advices ? Contact technical support
Specifications for PolyMide PA6-GF Grey - 1.75mm - 2 kg
Technologie / Produit
- Technology
- FDM
- Material
- PA
- Visual aspect
- Opaque, Mat
- Diameter
- 1.75 mm
- Sensitivity to humidity
- Strong
- Application
- Prototyping, Functional part
- Odour
- Yes
- Harmful
- Yes
- Level of difficulty
- Intermediate
- Type of product
- 3D Filament
- Colour
- Grey
- Net weight
- 2 kg
Valeurs techniques
- Glass transition temperature
- 70 °C
- Deflection temperature under load (0.45 MPa)
- 191 °C
- Deflection temperature under load (1.8 MPa)
- 157 °C
- Charpy
- 19 kJ/m² of energy
- Resistors
- Mechanical engineering, Wear and tear
- Composite
- Glass fibre
- Percentage of fibre
- 25 %
- Tensile modulus
- 4000 Mpa
- Flexural modulus
- 4000 MPa
- Tensile yield strength
- 70 MPa
- Tensile strength
- 100MPa
- Density
- 1.2 g/cm3
Extrusion
- Nozzle type
- Tempered steel, Ruby
- Type of consumable
- Non-proprietary filament (open system)
- Min. plateau temperature
- 25 °C
- Max. tray temperature
- 50 °C
- Min. extrusion temperature
- 280 °C
- Max. extrusion temperature
- 300 °C
- Min. speed
- 60 mm/s
- Max. speed
- 60 mm/s
- Minimum nozzle diameter
- 0.5 mm
- Bowden compatibility
- Yes
- Warping sensitivity
- Average
- AMS compatible
- Yes (with adapter)
Équipements spécifiques
- Closed printing enclosure
- Yes
- Filtration
- HEPA, Coal
Installation / Prérequis
- Type
- Filament on spool
- Box supplied
- Yes
- Coil material
- Plastic
