Ref. ELG-140009104

The Elegoo Mars 3 resin 3D printer is the first LCD 4K UV printer in the Mars series to feature a LCD 4098x2560 pixel screen. This Elegoo Mars 3 printer promises 30% more accurate prints than its smaller siblings.

The Mars 3 from Elegoo is equipped with a new, improved FEP film that improves the printing results of your 3D parts. The Elegoo Mars 3 also features a new lighting system based on COB LEDs. In addition, the Mars 3 from Elegoo has a much larger print volume than previous versions.

Sold out

The product is no longer available on our website.

However ✨, here is a new arrival and the product we recommend:

Delivery within 48/72 hours

Order before 1pm. Same day shipping

Free delivery

Free delivery near you from €69.90

Premium support

Our teams are on hand to answer all your questions

Over 2000 products

A wide choice of products from the biggest brands

Elegoo Mars 3: A high-volume printer with a screen LCD 4K

Elegoo has been known for several years now for its resin 3D printers, offering excellent value for money with affordable, well-built machines. With the Mars series, they have established themselves as one of the leaders in LCD printers.

The Elegoo Mars 3 is a new development in this legendary series of 3D printers. It offers a large print volume (143 x 89.6 x 175 mm), enabling you to print large resin parts. Its LCD 4K monochrome screen coupled with the new light source will add to its large volume an impressive quality of finish and a level of detail unequalled on the Mars series.

This Mars 3 printer is perfect for producing parts with a high level of detail and very high quality visual rendering.

New features and benefits of the Elegoo Mars 3

Compared with its smaller siblings, the Mars 3 from Elegoo brings a host of important new features that will improve your ease of use and the quality of your 3D prints. These new features and innovations are the result of months of research and development by Elegoo.

Elegoo Mars 3 - Écran LCD 4K

High-precision 4K screen LCD

Elegoo Mars 3 is equipped with a LCD 4K screen. This makes it the first printer in the Mars series to be so accurate. Its 4098x2560-pixel LCD 4K screen will enable X/Y precision of 0.035 mm, giving you an unrivalled level of detail on your 3D prints compared with LCD 2K printers.

Elegoo Mars 3 - Grand volume d'impression

Large print volume

This printer offers a large print volume for a desktop resin printer. This certainly makes it the resin printer with the best volume/price ratio in its range. Its volume is 30% greater than that of the Mars 2 Pro.

Elegoo Mars 3 - source lumineuse led cob

COB light source

COB (Chips On Board) LED technology is the best light technology currently available on the market. It offers high-performance light quality for ever more successful and detailed prints with greater reliability.

Elegoo Mars 3 - dissipation chaleur

Improved heat dissipation

The structure of Mars 3 has been redesigned to improve heat dissipation inside the 3D printer in order to limit undesirable temperature rises. This new system regulates the overall temperature in the printer enclosure and increases the lifespan of the printer's components.

Elegoo Mars 3 - Axe Z rail linéaire

Z-axis linear rail

A high-precision linear rail is installed on the Z axis of the Elegoo Mars 3 printer to optimise the overall precision of prints and layer changes.

Elegoo Mars 3 - Plateau sablé

Sandblasted platen for improved adhesion

The Mars 3's print platen is sandblasted and therefore rougher, considerably increasing the adhesion of parts to the platen. The new FEP 2.0 film also improves adhesion.

A top-flight Mars 3 printer

Equipped with the same advantages as its smaller sisters, the Mars 3 from Elegoo offers high-speed printing, with layers that can be polymerised between 1 and 3 seconds, enabling you to print your 3D models ultra-fast.

The printer's chassis, made from high-quality materials, will limit wear and tear over time. The printer also supports 12 languages, so you can configure it and choose the language you're most comfortable with.

Slicer Chitubox Pro Free

Elegoo offers you the Pro version of Chitubox (approximately 160€ / year) with every purchase of a Elegoo Mars 3 (After ordering the Elegoo Mars 3, Like and send a message to ELEGOO Official on Facebook to obtain the CHITUBOX Pro licence). The Chitubox slicer is the most widely used slicer with open resin and desktop 3D printers. This highly acclaimed slicer features a number of innovations and will guarantee successful slicing of your 3D parts and models.

The Pro version offered with your Mars 3 from Elegoo will take you even further, allowing you to integrate many additional CAD formats, advanced media management, several print profiles during the same print and many other advantages.

Resin compatibility and applications

Elegoo Mars 3 is compatible with all commercially available open resins. From standard, water-washable resins to flexible, technical resins.

This wide range of materials means you can add even more value to your parts and models, depending on their area of application. From prototypes to functional parts subject to mechanical constraints, you can print anything.

Thanks to its very high precision, you can print parts of very high visual quality for the production of visual prototypes, figurines or visual parts. More technical resins such as ABS-Like and Tough will enable you to make functional, mechanical or even production or replacement parts.

Lost-wax and dental resins will open up new possibilities in the dental and medical sectors in general. Lost-wax resins are also widely used in the jewellery industry to make custom moulds.

Print volume

143 x 89.6 x 175 mm

Layer thickness (precision)

10 microns

Maximum speed

30 mm/h

  • 🎯 We collaborate with businesses.
  • 📦 Stock in Europe
  • 🚚 Ships within 24 hours
  • 🔐 Secure payments
  • 🔙 14 days to change your mind
  • 📱 Need advices ? Contact technical support

Specifications for Elegoo March 3

Technologie / Produit

Technology
DLP
Print volume
143 x 89.6 x 175 mm
Layer thickness (precision)
10 microns
Maximum speed
30 mm/h
X/Y resolution
0.035 mm
Material
Resin Tough, Flexible resin, Dental Resin, Standard resin
Z-axis accuracy
0.00125 mm
Type of product
3D printer

Extrusion

Type of consumable
Non-proprietary resin

Polymérisation / Résine

Wavelength
405 nm
Automatic bin filling
No
Resin level sensor
No
Biocompatibility
Depending on resin used
Changes to the EFF
Yes
Screen type LCD
6.68-inch Monochrome LCD
Screen resolution LCD
4098 x 2560 px

Équipements spécifiques

Closed printing enclosure
Yes
Filtration
Coal
Resuming after an outage
Yes
Touch screen
Yes
Camera
No

Logiciel

Data transfer
USB
Slicer
Chitu DLP Slicer

Installation / Prérequis

Printer weight
6.2 kg
